솔리드웍스 50시간 완성 : 조립·도면편

신동진

기계설계&3D프린팅직업훈련교사이다.학생들의높은학업성취와무료로높은질의교육을받을수있도록온라인교육플랫폼을구축하고있다.앞으로더좋은교육을제공하겠다.감사하다._작가의말.국가/민간자격‘기계가공기능장외11개’,중등교사자격‘중등학교정교사2급(기계금속)’,직훈교사자격‘기계설계2급외15개’를보유하고있다.저서로『오토캐드40시간완성』,『인벤터50시간완성<모델링편>』,『인벤터50시간완성<조립/도면편>』,『3D프린터운용기능사실기30시간완성<인벤터편>』,『지더블유캐드50시간완성』등이있다.

PART13D형상모델링조립
1.1조립품생성8
1모델링파일관리...........................................................8
2조립계획......................................................................10
3조립계획구상..............................................................11
4작업환경설정,조립품템플릿저장..................................13
5조립품생성...................................................................19
1.2간섭탐지및수정40
1간섭탐지......................................................................40
2간섭수정......................................................................45
3조립품오류의원인과해결방법.....................................51
4데이터호환및저장.......................................................54
5표준규격품의활용........................................................57
6솔리드웍스툴박스의활용..............................................59
조립실습(초급,중급)....................................................68
조립실습(고급).............................................................69

PART23D형상모델링분해
2.1분해도생성72
1분해도생성...................................................................72
2조립분해영상제작.......................................................81
3분해지시선스케치........................................................84
분해실습(초급,중급)....................................................88
분해실습(고급).............................................................89

PART33D형상모델링도면
3.1조립도및분해도작성92
1엔지니어링모델링구조체계.............................................92
2한국산업표준.................................................................94
3표준규격의의미............................................................94
4기계제도의정의............................................................94
5도면의크기...................................................................95
6도면의양식...................................................................95
7도면의척도...................................................................95
8선의용도에따른종류와굵기.........................................96
9작업환경설정,도면템플릿저장.....................................97
10속성탭빌더,사용자정의속성.....................................114
11조립도,분해도작성프로세서.......................................119
12도면양식수정..............................................................120
13뷰(투상도)배치............................................................122
14분해지시선스케치......................................................125
15부품번호삽입.............................................................128
16BOM(부품리스트)삽입...............................................130
17도면출력....................................................................139
3.2부품도작성144
1부품도작성프로세스....................................................144
2뷰의종류......................................................................153
3도면양식수정................................................................160
4뷰(투상도)배치..............................................................165
5치수,일반허용차,끼워맞춤공차기입..............................176
6표면거칠기기호기입.....................................................181
7기하공차기입...............................................................185
8주서기입.....................................................................187
9부품리스트삽입...........................................................191
<붙임>규격품경로...........................................................193
<붙임>연습도면1.경첩....................................................194
<붙임>연습도면2.펜치...................................................195
<붙임>연습도면3.캐스터................................................196
<붙임>연습도면4.도어가이드........................................197
<붙임>연습도면5.바이스................................................198
<붙임>연습도면6.글로브밸브........................................199
<붙임>연습도면7.2열V벨트유동장치............................201
<붙임>연습도면8.동력전달장치......................................204
